Stihl BR 800 Service Manual

BR 800 3
1.1 Applicable Documentation
N Please observe the following documentation in
addition to this service manual.
– Spare parts documentation
– TI bulletins
– Instruction manual
1.2 Symbols in Text
2.1 Protective Gloves
Sharp or hot components can cause cuts or burns.
N If sharp or hot components have to be handled during
a repair: Wear protective gloves.
2.2 Safety Glasses
Particles and objects can be thrown into the air at high
speed during a repair. Thrown particles or objects can
cause eye injuries.
N If there is a risk of particles being thrown during the
repair: Wear safety glasses.
2.3 Spare Parts
If spare parts not approved by STIHL are installed, they
may not fulfill the required function or deactivate safety
devices. This can result in serious or fatal injuries.
N STIHL recommends the use of genuine STIHL
replacement parts.
3.1 Preparing the Blower
N Drain the fuel tank into a container approved for fuels.
N Clean the blower.
1 About this Service Manual
This symbol refers to a chapter in this service
manual.
A video is available for this chapter
This symbol shows the tightening torque for a
screw joint and the procedure after tightening.
In this example: Tightening torque 5 Nm. Then
rotate 1 full turn counterclockwise.
2 Safety During Repair Work
3 Preparations for Repair
5 Nm
1

Stihl BR 800 Specifications

General

Type	Backpack blower
Airflow	2025 m³/h
Suction mode	-
Product color	Black, Orange, White
Airspeed (max)	349.2 km/h
Power source	Gasoline
Sound power level	112 dB
Sound pressure level	104 dB

Weight and Dimensions

Weight	11700 g
