Stihl MS 240

105MS 240, MS 260, MS 260 C
– Pull the heater switch (1) out a
little.
: Pull the grommet (2) off the
heater switch (1).
: Pull the connector sleeve (1) out
of the heater switch.
– Check the heater switch and
replace it if necessary.
: Push the connector sleeve (1)
into the switch.
: Push the grommet (2) over the
switch.
165RA422 TG
1
2
165RA423 TG
1
165RA424 TG
1
2
: Position the heater switch with
the groove (arrow) facing up.
– Push the heater switch into the
tank housing recess.
– Fit the ground wire on the heater
switch, b 15.4.1
– Secure the handlebar, b 11.5
– Install the carburetor and, on
versions with carburetor heating,
connect up the thermostatic
switch, b 14.2, b 15.1
– Check operation.
– Reassemble all other parts in the
reverse sequence.
– Tightening torques, b 3.5
15.4.1 Heater Switch Ground
Wire
A faulty ground wire may impair or
prevent operation of the heating
system.
– Check for contact and continuity
and replace ground wire if
necessary,
165RA352 TG
– Remove the sprocket cover and
cutting attachment, b 5
: Take out the screw (arrow).
– Remove the ground wire (1).
– Unscrew the handlebar and turn
it to one side, b 11.5
: Pull the ground wire (1) out of the
opening (arrow) in the tank
housing.
165RA426 TG
1
165RA427 TG
1
