Overview 3
Truck description
Driver's overhead guard
WARNING
Danger of injuring
The overhead guard of the industrial truck descri-
bed here is not suitable for providing protection
against very small objects. If very small objects
need to be transported, the overhead guard must
be modified accordingly.
Truck description
You can find information about how to operate
the individual functions in the corresponding
chapters.
General information
The driver can put himself and the load
suspension device into the most suitable
working height by raising the driver's cabin.
The additional lift can be used to serve the
highest rack level and to set a favourable
deposit height when carrying out order picking
work. The lift must always remain in the lowest
position possible when travelling.
In the narrow aisle the order pickers are guided
either mechanically or inductively (please see
chapter Optional equipment).
If the aisles are wide enough, the industrial
trucks can be driven freely with the load low-
ered. All movements (driving, lifting/lowering
main lift [cab lift], lifting/lowering auxiliary lift)
are infinitely adjustable.
Operating errors can be prevented to a large
extent by means of safety circuits. Up to a cab
lift height of 1.2 m, the cab barriers may be
left open when the truck is being driven. If the
truck is driven at a lift height of greater than
1.2 m, the barriers must be closed.
NOTE
On the version with a simplex mast and
auxiliary lift, the changeover point for all of the
affected functions is not at 1.2 m, but instead at
approximately 0.4 m. If this height is reached,
the Barrier symbol appears in the display if the
truck is equipped with an LCD display.
*Option
521
2 804 3001 EN - 02/2017 27
