Technical data 6
Driving speeds
Driving speeds
There is automatic adjustment of the maxi-
mum possible driving speed to the situation at
that moment.This depends upon:
– the height of the platform h
12
– the steering angle
– the guidance method
– and any optional equipment*
Driving speeds without automatic guidance, truck with auxiliary lift
Lifting height cabin floor h
12
Steering angle
maximum driving speed v
max
<350 mm
-
≈9,0 km/h
>350 mm <2150 mm
<±10°
≈4,0 km/h
>350 mm <2150 mm
>±10°
≈2,5 km/h
>2150 mm
-
≈2,5 km/h
.
Driving speeds wit
hout automatic guidance, truck without auxiliary lift
Lifting height cabin floor h
12
Steering angle maximum driving sp
eed v
max
<1200 mm
-
≈9,0 km/h
>1200 mm <3000 mm <±10°
≈4,0 km/h
>1200 mm <3000 mm >±10°
≈2,5 km/h
>3000 mm
-
≈2,5 km/h
.
Driving speeds with automatic guidance* with speed optimization*
Lifting height
cabin floor h
12
Steering angle
maximum driving speed v
max
<2000 mm
≈0°
≈10,0 km/h
>2000 mm <3200 mm
≈0°
≈10,0 km/h to 2,5km/h stepless decreasing
>3200mm
≈0°
≈2,5 km/h
.
Driving speed in pedestrian mode*
The maxim
um possible driving speed is 2.5
km/h in ped
estrian mode.
521
2 804 3001 EN - 02/2017 93
