Operation 4
Parking, decommissioning
Additional lift, load-side operation
(1) Lift the auxiliary lift.
(2) Lower the auxiliary lift.
(3)Buttontobeactuatedbytheoperator's
second hand when using (1) and (2)
(4) Not assigned, reserved for options.
These industrial trucks can optionally be
equipped with load-side operating controls
for the auxiliary lift.
Parking, decommissioning
Parking and leaving the truck
NOTE
It is the operator's duty to remove the ignition
key when he leaves the truck, thus securing
the truck against unauthorised use. If the
truck is equipped with an electronic access
control, it must be reset and/or the device for
controlling access must be removed. Where
possible, the truck should be parked at the
start of a racking aisle or in a loading bay. If
there are parking spaces, the truck must be
parked there. The fork is to be lowered to the
floor as far as possible, and if there is one, the
tilt attachment must tilt towards the floor to
reduce the risk of stumbling.
Decommissioning
ENVIRONME
NT NOTE
If the ind
ustrial truck described here has to be
taken out
of operation, make sure that all com-
ponents are
disposed of in accordance with
the valid guidelines. The used consumables
in particular are to be recycled or disposed of
correctly.
521
2 804 3001 EN - 02/2017 69
