Still RX70-35 - Controlling the Lifting System Using the Joystick 4 Plus

– Move the "lifting/lowering" operating lev-
er(3) in the direction of the arrow(A).
Tilting the lift mast
To tilt the lift mast forwards:
– Move the "lift mast" operating lever(4) in
the direction of the arrow(C).
To tilt the lift mast backwards:
– Move the "lift mast" operating lever(4) in
the direction of the arrow(D).
Movements of the lifting system and
meanings of the pictograms
A Lowering
B
Lifting
C
Tilting forwards
D
Tilting backwards
Controlling the lifting system us-
ing the Joystick4Plus
DANGER
Reaching into or climbing between moving parts
of the truck (e.g. lift mast, sideshifts, working equip-
ment, load carrying devices etc.) can lead to seri-
ous injury or death and is therefore prohibited.
– Observe the safety regulations for handling loads.
– Only operate the lifting system from the driver's
seat.
Operation
4
Lifting
 19757378011527EN-12/2023 - 07
