3.5.2 Ethernet connection to a Local Area Network (LAN)
The VSAT IDU may be connected to a single PC or to a network via the RJ-45 Ethernet jack on the back
panel.
Plug one end of the Ethernet cable into the RJ-45 jack on the back panel.
Plug the other end of the Ethernet cable into the RJ-45 jack a Local Area Network (LAN) device,
such as an Ethernet hub, switch, or router, according to its manufacturer‘s instructions.
The SatLink VSAT will auto-detect if Ethernet HUB or NODE mode is used and will automatically chose
the correct mode; hence there is no need to use a cross-over Ethernet cable for direct connections to PCs.
3.5.3 Power Connection
The SatLink 1910 and 2900 models have internal power supply and consequently are connected directly
to a 110/230 VAC 50/60Hz outlet using a standard 230 VAC power cord.
3.5.4 Power supply
The SatLink 1000 and 2000 have an external power supply that is connected to a 110/240 VAC 50/60Hz
outlet using a standard power cord.
The SatLink 1000 and 2000 must only be connected to the external power supply that is
approved by STM, PN 104170 (LEI-S2425D/Adapter Technology, Model No. STD-2425).
Use of another power supply will void warranty.
