7.3 Device Status
The Device option in the SatLink web interface displays the device status information as displayed in the
following figure and table. Select the Device option on the SatLink web interface home page to open the
Device status page.
Figure 36: Device Status
Parameter
Description
Model
VSAT hardware model
Software version
This specifies the version number (including build number) of the application software
currently running.
LAN MAC
address
MAC address of the LAN (Ethernet) interface of the VSAT.
DVB MAC
address
MAC address of the DVB (satellite) interface of the VSAT.
System UP Time
Time elapsed since last VSAT boot.
System time
UTC time (only displayed if UTC time is broadcasted by the Gateway).
CPU load
Current load of VSAT CPU.
System name
Specifies the Name of VSAT. This and the following two parameters are MIB objects in the
MIB-II systems group and can be set via SNMP or from the CLI using the ―device‖ menu.
System contact
Name of the contact person and/or company, who is responsible for this VSAT.
System location
This determines the Location of the VSAT.
ODU Serial
Number
Specifies the serial number of the ODU for VSATs configured with a SatLink 403x ODU.
ODU HW
Version
Specifies the HW revision for VSATs configured with a SatLink 403x ODU.
