11. Quality of Service
QoS is used to provide differentiated handling of different types of IP traffic. The aim is to be able to
satisfy traffic flows for applications with different requirements, while at the same time minimizing the
required bandwidth on the Return Link. For example, QoS is used to assure a given Return Link
bandwidth with minimal delay jitter for VoIP or Video real time traffic by avoiding influence from traffic
that is not so sensitive to delay jitter — e.g., web browsing and FTP.
The VSAT does QoS differentiation on the Return Link based on the DiffServ architecture and can work
in networks that offer performance as per hop behavior (PHB) as defined in the DiffServ architecture.
QoS on the Forward Link is handled by the DVB-RCS Hub alone, and not discussed further in this
manual.
The VSAT supports use of the following PHBs and PHB groups on the Return Link
5
:
 Best Effort (BE) PHB
 Critical Data (CD) PHB
 Real Time Video Conferencing (RT-ViC) PHB group
 Real Time Voice over IP (RT-VoIP) PHB group
Internally, the VSAT classifies the traffic that shall be sent on the Return Link into different QoS groups.
One or more QoS groups will then be mapped to a PHB / PHB group in the network. The VSAT
internally supports the following QoS groups:
QoS Group ID
QoS Group Name
Maps to PHB
0
Best Effort
Best Effort (BE)
1
VoIP Audio
Real Time Voice over IP (RT-VoIP)
2
VoIP Signaling
Real Time Voice over IP (RT-VoIP)
3
ViC Video
Real Time Video Conferencing (RT-ViC)
4
ViC Audio
Real Time Video Conferencing (RT-ViC)
5
ViC Signaling
Real Time Video Conferencing (RT-ViC)
6
Critical Data
Critical Data (CD)
The QoS implementation in the VSAT is based on a multi-field classifier, i.e., the DSCP/TOS field and
other fields in the IP header are used to classify which QoS group each IP packet belongs to. IP packets
belonging to different QoS groups are then treated differently by the VSAT. The VSAT can be configured
to support traffic differentiation based on DSCP values as used in DiffServ based networks.
Associated with each QoS group is a QoS policy. Parameters that impact the QoS policy are:
 Capacity request algorithm and parameters
- The capacity request algorithms for real-time traffic are tailored to request a continuous rate
capacity.
- The capacity request algorithms for best effort and critical data are designed for more bursty and
delay insensitive traffic such as Web browsing and FTP.
 Transmission PID or VPI/VCI
- Used to give precedence to real-time traffic when interleaving traffic from different QoS groups
at the MPEG/ATM level.
 Drop policy
- Real-time traffic packets are dropped at the head of the transmission queue if the queue
overflows, while best effort traffic packets are dropped at the tail of the queue.
5
Critical Data and Real Time Video Conferencing are only available on the STM SatLink 1000, 1900,
1901, 2000, and 2900 when the software license key for 4 QoS classes has been set (see section 18.3).
