Rx State : On
DVB State : Forward Link up
Network : 1326, Carrier-Class
Frequency : 11.249986 GHz
Symbol Rate : 24.499864 Msps
S2 ModCod : 7 QPSK-3/4
Pilot : On
Frame length : Long frame
DVB S2 Mode : CCM
Roll off : 0.25
SNR : 9.8 dB
Input Power : -27 dBm
To enable the Forward Link:
dvb rx fwdlink <idx> -enable
Example:
# dvb rx fwdlink 1 -enable
# dvb rx show
Satellite (DVB) RX Configuration
--------------------------------
Auto start : Enabled
RX watchdog : 15 minute
Idx Pri SymbRate[Msps] Freq[GHz] Mode PopId Enable
* 0 2 24.500000 11.250000 DVB-S2 2 Yes
1 3 1.200000 30.000000 DVB-S2 2 Yes
2 0 11.900000 11.000000 DVB-S2 2 Yes
Satellite (DVB) Receiver Status
--------------------------------
Rx State : On
DVB State : Forward Link up
Network : 1326, Carrier-Class
Frequency : 11.249986 GHz
Symbol Rate : 24.499864 Msps
S2 ModCod : 7 QPSK-3/4
Pilot : On
Frame length : Long frame
DVB S2 Mode : CCM
Roll off : 0.25
SNR : 9.5 dB
Input Power : -27 dBm
9.3 Line-up
Perform antenna and ODU installation and alignment as described in Appendix F and the initial
parameter configuration described in section 9.2 before proceeding with the procedures described here.
9.3.1 Forward Link Acquisition
Connect the RX cable between the ODU and IDU (if not already connected). Verify that the RX power
level is between -25 dBm and -65 dBm at the input of the IDU.
