Satellite Receiver Status
The satellite receiver status option displays the detailed view of the receiver status. The operator can view
the receiver state, network ID, network name, mode, FEC rate, modulation, roll-off, frame length, pilot,
transmission mode, error rate, frequency, SNR, symbol rate, and Rx Input power of the satellite receiver.
Parameter
Description
State
Specifies the receiver state. During normal operation it reads "Forward Link up".
Network ID
This determines the DVB network ID of the Forward Link.
Network Name
The DVB network name of the Forward Link.
Mode
This specifies whether the Forward Link is a DVB-S or DVB-S2 carrier.
FEC rate
Detected FEC rate on the Forward Link.
Modulation
Specifies the detected modulation of the Forward Link.
Roll-off
Detected Roll-off factor of the Forward Link.
Frame length
Long or short frame
Pilot
Off or On
Transmission mode
CCM or ACM
Error-rate
The number of errors detected by the Viterbi decoder during a fixed time period.
Frequency
The measured receive frequency for the Forward Link.
SNR
This determines the current measured signal to noise ratio for the received Forward Link
signal.
Symbol rate
The measured symbol rate for the Forward Link.
Rx Input power
Satellite Transmitter Status
The satellite transmitter status option displays the detailed view of the receiver status. The operator can
view the transmitter state, IDU output power, ODU output power, EIRP, Frequency offset, Timing offset,
Capacity and SNR of the satellite transmitter.
