R2W PLUS
65
● Refer to “4.5.1” to set coordinate of occupied point.
Operation steps
Keys
Display
①
Click “PLANE Offset” key.
【PLANE
Offset】
②Collimate prism P1, and
click “Measure” key.
【Measure】
