strapex SMA 30 - Page 58

03.11
Strapex SMA 30
58  Pos. Artikel-Nr. Benennung Partname Article Stück   Partno    Quantity   Nod'article    Pièce  * EmpfohleneErsatzteile * Recommendedspareparts * Piècesderechangerecom.
Fig.D Maschinengestell,Teil1 Machineframe,part1 Bâtidelamachine,partie1 
 1 A93N-300001-0 Winkel FrontUpperCover(L) PlateauTable(L) 1
 2 A93N-300002-0 Winkel RearUpperCover(L) PlateauTable(L) 1
 3 A93N-300003-0 Winkel RearUpperCover(R) PlateauTable(R) 1  4 A93N-300004-0 Rückwand RearPanel Couverde 1  5 A93N-300005-0 TischplatteVorne(850W) UpperTableFront(850W) PlateauTableCpl.(850W) 1  6 A93N-300006-0 Tischplattehinten(850W) UpperTableRear(850W) PlateauTableCpl(850W) 1  7 A93N-300007-0 Grundplatte SpringHingePad Support 4  9 A93N-300009-0 Platte Archsideplate(L) Plaque(L) 1
 10 A93N-300150-0 Halter ArchSupport(L) FixationdeGaine(L) 1  11 A93N-300020-0 Türelinks LeftDoor(OutsideTensionAdjust) Portegauche 1
 12 A93N-300350-0 Bodenblech FrontBottomPanel(R) PlaquedeBase(R) 1  13 A93N-301001-0 Halter CasterHolder(Option) Support 4  14 A93N-301002-0 Platte CasterHolderStrengthenPlate(Option) Plaque 4  15 A93N-301050-0 Halter CasterSupport(Option) Support 1  16 A93N-310450-0 Untergestell Frame Châssis 1  17 A77-300005-0 Scharnier SpringHinge(R) FourchettedePalier 3  18 A77-300006-0 Scharnier SpringHinge(L) FourchettedePalier 2  19 A77-321150-0 Tür RightDoor Pote 1  20 A93-300016-0 Bodenblech FrontBottomPanel PlaquedeBase 1  21 A20-321001 Tischrolle TableRoller Rouleau 8  22 A20-321002 Welle TableRollerShaft Arbre 8  23 S35-300027 Griffschale EdgeGuard ProtectionàMain 3  24 A20-300021-0 Winkel MagnetCatchHolder Support 1  25 A93-300004 Scharnierplatte MountingPlate Rondelle 1  26 A93-320005 Support Support Support 1  27 A93-320006 Support Support Support 1  28 A20-300006 Magnet Magnet Aimant 1  29 A93-900004 Laufrolle Caster RoueGuide 4  30 A20-300015 Kunststoff-Scheibe NylonWasher RondelleSynthetique 1  31 A20-320005 Griff TableHandle Poignée 4  32 A20-300018 Bodenblech MagnetStopper Support 1  33 A93-900005 Laufrollenbrense Caster Roue 2  34 A93N-300010-1 Winkel Cover(Lower) Couvercle 1  35 A20-511010-2 Blechwinkel ProximitySwitchBase Cornière 1
* 36 E07-090027 SchalterTLQ5MC2/12VTO24VDC ProximitySwitchTLQ5MC2/12VTO24VDC Cellulephoto-électriqueTLQ5MC2/12VTO24VDC 1
 37 A93N-300013-0 Rückwand(A-93NC) RearPanel(A-93NC) Couvercle(A-93NC) 1  38 A93N-300014-0 Platte(A-93NC) Plate(A-93NC) Plaque(A-93NC) 1  39 C-54222-300 Untergestellhalterung(A-93NC) FrameStopper(A-93NC) Support(A-93NC) 1  40 A20-230004 Grundplatte Fixedplate Support 1
