5. Unsnap the two secure snaps (C) at the foot end corners (Figure 9).
6. Unsnap the two foot end corner retainers (B) (Figure 9).
7. Insert a zipper pull tool or equivalent through the hole in the zipper slider to unlock.
8. Unzip the support surface top cover from the bottom cover using the zipper pull tool or equivalent (A) (Figure 9) and stop
unzipping at the middle of the opposite side (D).
NNoottee -- The zipper starts on the patient right side near the foot end.
FFiigguurree 99 –– TToopp ccoovveerr
9. Fold the cover up toward the head end.
10.Separate the six Velcro® connectors holding the foot section gel crib to the pod assembly.
11.Remove the foot section gel crib (F) by lifting upward (Figure 10). Save gel crib.
12.Unsnap the two snaps that secure the bottom support surface cover to the foot box.
EN 32 2971-009-002 Rev D.0
