BBUUTTTTOONN NNAAMMEE FFUUNNCCTTIIOONN
SUCTION UNITS
(PREFERENCES)
(international models of the
rover only)
The SUCTION UNITS button will appear disabled for US
customers.
UP/INCREASE
Touch and hold to scroll up a list of options or increase a
setting value.
TTaabbllee 55 –– SSeeccoonnddaarryy CCoonnttrrooll PPaanneell BBuuttttoonnss
BBUUTTTTOONN NNAAMMEE FFUUNNCCTTIIOONN
ABORT
Touch to abort a wash or extended wash cycle while the
time remaining in the cycle is greater than or equal to
three (3) minutes. When selected, a quick drain cycle will
occur.
EXTENDED WASH
Touch to drain the contents of the canister, apply
detergent to the interior walls of the canister, and rinse
the detergent with water. Intermittent periods of soaking
occur during the cycle.
NORMAL WASH
Touch to drain the contents of the canister, apply
detergent to the interior walls of the canister, and rinse
the detergent with water. More rinse cycles occur.
QUICK WASH
Touch to drain the contents of the canister, apply
detergent to the interior walls of the canister, and rinse
the detergent with water. Fewer rinse cycles occur.
RELEASE
Touch to disengage and release the rover from the
docker after completion of a wash cycle.
TTaabbllee 66 –– MMaaiinn CCoonnttrrooll PPaanneell DDiissppllaayy SSyymmbboollss
SSYYMMBBOOLL DDEEFFIINNIITTIIOONN
Adjust Brightness (menu dialog)
Audible Indicator Loudness (menu dialog)
Fluid Level Gauge with two liter increment marks/values. See Fluid Level Gauge/Indicator Colors.
Manifold. See Manifold Symbol Screen Colors.
700000969828 Rev-AA 27 EN
