Operation
Securing the patient with the G-rated restraint straps (Continued)
Adjusting restraint straps (Continued)
Figure 20: Buckle the straps around
the patient
Figure 21: Lengthen the restraint
strap
Figure 22: Shorten the restraint
strap
Securing a patient with the X-restraint/RUGGED™-X (6500-001-430/6506-001-430)
restraint straps
Secure restraint straps to the cot in the required attachment locations: shoulders waist, thighs, and ankles.
WARNING
• Always use all restraint straps to secure the patient on the cot. An unrestrained patient may fall from the cot.
• Do not attach restraint straps to the base tubes or cross tubes.
CAUTION
Do not entangle the restraint straps in the base frame when you raise or lower the cot.
Note: Restraint straps are a Type BF applied part.
Restraint strap attachment locations should provide strong anchorage and proper restraint position (Figure 23 on page 45
). Do not allow restraint straps to interfere with equipment or accessories. Buckle the restraints across the shoulders,
waist, thighs, and ankles. Buckle all restraint straps when the cot is not in use.
1. Installing the X-restraint/RUGGED-X shoulder restraints on page 45
2. Installing the X-restraint/RUGGED-X waist restraints on page 46
3. Installing the X-restraint/RUGGED-X thigh restraints on page 46
4. Installing the X-restraint/RUGGED-X ankle restraints on page 47
5. Installing the X-restraint/RUGGED-X ankle restraints on page 47
