Operation
Installing the defibrillator platform (Continued)
7. Make sure that the defibrillator platform is secured to the product.
8. Place the defibrillator on the defibrillator platform.
9. Secure the straps (E) to hold the defibrillator on the defibrillator platform (Figure 41 on page 52).
Figure 40: Tab
E
F
Figure 41: Attach defibrillator platform to the cot
Note: If the defibrillator platform is not attached to the product after you connect both latch hooks, unlatch the tab. To
adjust, loosen or tighten the strap and then push the tab up until it locks into place with an audible click.
Hanging equipment from the equipment hook
Use the equipment hook to hang additional accessories or equipment, such as defibrillators and monitors.
CAUTION
• Do not load the equipment hook above the safe working load of 35 lb (15.8 kg).
• Always remove all accessories or equipment from the equipment hook when in the vehicle.
