Stryker Power-PRO XT - Guidance and manufacturers declaration - electromagnetic immunity

76 6506-209-001 REV F www.stryker.com
EMC information
CAUTION
Avoid stacking or placing other equipment adjacent to Power-PRO and SMRT charger to prevent improper operation of
the products. If such use is necessary, carefully observe Power-PRO and SMRT charger and the other equipment to
make sure that they are operating properly.
Recommended separations distances between portable and mobile RF communications equipment and Power-
PRO and SMRT charger
Power-PRO and SMRT charger are intended for use in an electromagnetic environment in which radiated RF
disturbances are controlled. The customer or the user of Power-PRO and SMRT charger can help prevent
electromagnetic interferences by maintaining a minimum distance between portable and mobile RF communications
equipment (transmitters) and Power-PRO and SMRT charger as recommended below, according to the maximum
output power of the communications equipment.
Rated maximum output
power of transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz to 80 MHz
D=(1.2) (√P)
80 MHz to 800 MHz
D=(0.35) (√P)
800 MHz to 2.5 GHz
D=(0.70) (√P)
0.01 0.12 0.04 0.07
0.1 0.38 0.11 0.22
1 1.20 0.35 0.70
10 3.79 1.11 2.21
100 12 3.50 7
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters
(m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output
power rating of the transmitter in watts (W) according to the transmitter manufacturer. Note 1: At 80 MHz and 800 MHz,
the separation distance for the higher frequency range applies. Note 2: These guidelines may not apply in all situations.
Electromagnetic propagation is affected by absorption and reflection from structures, objects, and people.
Guidance and manufacturer’s declaration - electromagnetic immunity
Power-PRO and SMRT charger are suitable for use in the electromagnetic environment specified below. The
customer or the user of Power-PRO and SMRT charger should assure that they are used in such an environment.
Immunity test
IEC 60601 test level
Compliance level
Electromagnetic
environment-guidance
Electrostatic discharge
(ESD)
IEC 61000-4-2
+6 kV contact
+8 kV air
+6 kV contact
+8 kV air
Floors should be wood,
concrete or ceramic tile. If
floors are covered with
synthetic material, the
relative humidity should be
at least 30%.
Electrostatic fast
Transient/burst
IEC 61000-4-4
+2 kV for power supply
lines
+1 kV for input/output lines
Power-PRO: N/A
SMRT charger (6500-201-
010): +2kV for power
supply lines
+1 kV for input/output lines
Mains power quality should
be that of a typical
commercial or hospital
environment.
