Stryker SV1 Service Manual

www.stryker.com SM-7100 REV 01 27
Quick reference replacement parts
Kit name Number Kit contents
Number Name
Quantity
Siderail kit, foot end
right, dark blue, see
Siderail foot end
assembly on page
85
YM-KIT-100014-B YM-02-144-MN
Right foot siderail
assembly
1
HM-22-1780 3M primer 94
handkerchief
1
HM-12-FTR005 12-FTR005 shock
absorber connection
pin
1
HM-02-283 2 mm plastic washer
(10 mm plastic
washer) mould NO
34
6
HM-11-05
6 mm C shape snap
ring DIN 6799
1
HM-11-19
Q10 capped snap
ring (DT/6668/44A)
4
HM-12-144 12-144 10 x 128 mm
siderail pin
1
HM-12-145 12-145 10 x 305 mm
siderail pin
1
HM-20-854
Dark blue (Stryker)
lower right siderail
color sticker
1
Siderail kit, foot end
right, dark wood, see
Siderail foot end
assembly on page
85
YM-KIT-100014-D YM-02-144-MN
Right foot siderail
assembly
1
HM-22-1780 3M primer 94
handkerchief
1
HM-12-FTR005 12-FTR005 shock
absorber connection
pin
1
HM-02-283 2 mm plastic washer
(10 mm plastic
washer) mould NO
34
6
HM-11-05
6 mm C shape snap
ring DIN 6799
1
HM-11-19
Q10 capped snap
ring (DT/6668/44A)
4
HM-12-144 12-144 10 x 128 mm
siderail pin
1
HM-12-145 12-145 10 x 305 mm
siderail pin
1
HM-20-761
08 dark wood future
siderail color foot
right
1
