www.stryker.com SM-7100 REV 01 59
Service
Nurse control pendant replacement (Continued)
Procedure:
1. Apply the brakes.
2. Raise the product to the highest height position.
3. Power down the bed and unplug the power cord from the wall outlet.
4. Using diagonal pliers, cut and discard the cable tie that secures the fowler (backrest) actuator cable to the wire
routing channel.
5. Remove the three cable routing covers that secure the gatch (legrest) actuator cable to the litter frame.
6. Unplug the nurse control pendant cable from the junction box.
7. Dispose of the nurse control pendant.
8. Reverse steps to reinstall.
9. Verify proper operation of the product before returning it to service.
Siderail control panel (inside and outside siderail) replacement
Tools required:
• Flat screwdriver
Procedure:
1. Apply the brakes.
2. Raise the product to the highest height position.
3. Power down the bed and unplug the power cord from the wall outlet.
4. Remove the part number label from the head side of the control box assembly.
5. Using a flat screwdriver, carefully pry the outer panel away from the siderail hoop until the hoop fully unsnaps from
the inner panel.
6. Unplug the cable connecting the siderail control panel to the junction box.
7. Remove and discard the siderail control panel.
8. Reverse steps to reinstall.
9. Verify proper operation of the product before returning it to service.
Control box replacement
Tools required:
• Diagonal pliers
• Small flat screwdriver
• 3/8 in. drive ratchet
• 10 mm socket
• 10 mm combination wrench
Procedure:
1. Apply the brakes.
2. Raise the product to the highest height position.
3. Power down the bed and unplug the power cord from the wall outlet.
4. Turn the battery off using the nurse control.
5. Raise and lock the lower leg section in the highest position.
6. Using a small flat screwdriver, un-clip the actuator cable retainer (A) from the control box (Figure 12 on page 60).
7. Remove and save the actuator cable retainer.
To Next Page
