80 SM-7100 REV 01 www.stryker.com
Fowler (backrest) actuator
Item Number Name
Quantity
A HM-17-248
312887-00 future LB
release backrest actuator
Linak type
1
B
HM-11-03
10 mm snap ring DIN 471
2
C HM-12-FTR004
12-FTR004 10 x 53
actuator pin
2
