Stryker SV1 - Headboard and Footboard Assembly

www.stryker.com SM-7100 REV 01 87
Headboard and footboard assembly
Item Number Name
Quantity
A HM-06-49
3.9 x 16 mm drill head
smart screw
4
B HM-12-150
Ø18 x 4 mm head pipe
2
C YM-20-013
Head or foot board
polypropylene
1
Headboard laminate Number
Dark blue HM-20-851
Dark wood HM-20-763
Light wood HM-20-753
Wood HM-20-758
Footboard laminate Number
Dark blue HM-20-850
Dark wood HM-20-763
Light wood HM-20-753
Wood HM-20-758
