Stryker SV1 Service Manual

16 SM-7100 REV 01 www.stryker.com
Quick reference replacement parts
These parts are currently available for purchase. Call Stryker Customer Service: 1-800-327-0770 for availability and
pricing.
Name Number
Chassis, upper backrest
YM-008-013-LM-BY
Chassis, upper chassis leg rest
YM-007-006-BY
Chassis, upper middle
YM-006-003-BY
Control unit, siderail
HM-17-310
HM-17-311
CPR handle
HM-02-13
IV pole height adjustment plastics, kit HM-20-127
IV pole bottle holder plastics, kit HM-20-128
Multi junction box (MJB) HM-17-156
HM-17-183
Release wire HM-20-206
Kit name Number Kit contents
Number Name
Quantity
Actuator kit, fowler
(backrest), see
Fowler (backrest)
actuator on page 80
YM-KIT-100006 HM-11-03 10 mm snap ring DIN
471
2
HM-12-FTR004 12-FTR004 10 x 53
actuator pin
2
HM-17-248
312887-00 future LB
release backrest
actuator Linak type
1
HM-17-184 0961006-B high/low
actuator snap ring
1
Actuator kit, gatch
(legrest), see Gatch
(legrest) actuator on
page 81
YM-KIT-100007 HM-02-283 2 mm plastic washer
(10 mm plastic
washer) mould NO
34
2
HM-11-03 10 mm snap ring DIN
471
3
HM-12-FTR004 12-FTR004 10 x 53
actuator pin
1
HM-12-FTR006
12-FTR006 calf pin
1
HM-17-249
J04257 future LB
legrest actuator
Linak type
1
YM-HM-02-285
7 mm PLS washer
(10 mm thick washer
new type)
2
YM-HM-02-287
10*14 mm PLS
washer mould NO 36
2
