Stryker SV1 Service Manual

www.stryker.com SM-7100 REV 01 17
Quick reference replacement parts
Kit name Number Kit contents
Number Name
Quantity
Actuator kit, lift, see
Hi-Lo actuators on
page 73
YM-KIT-100008 HM-11-03 10 mm snap ring DIN
471
2
HM-12-112
12-112 Ø10 x 39.5
mm stepped pin
1
HM-12-FTR004 12-FTR004 10 x 53
actuator pin
1
HM-17-100 J03648 (31410H
+1115004K CB16
Linak high/low
actuator)
1
HM-17-184 0961006-B high/low
actuator snap ring
1
Battery replacement
kit, see Control box
and battery on page
74
YM-KIT-100001 HM-05-043 M5*20 imbus bolt
4
HM-07-22 M6 iron washer
(small)
4
HM-08-04
M5 fibered nut
4
HM-16-03
Ø25 clips (UB250C-
N 245X4, cable
connector)
2
HM-17-16 BA1812-1300-000
Linak CB6 battery
1
Brake pedal
replacement kit, see
Brake system on
page 64
YM-KIT-100037 HM-05-135 6*20 steel bolt
1
HM-07-22 M6 iron washer
(small)
1
HM-08-05
M6 fibered nut
1
HM-11-10 11 mm snap ring
(lipper) KMS starlock
push on BV/6706
fastener
1
HM-11-20
Q11 capped snap
ring DT/6673/44A
2
HM-12-905
Transfer laser cut
part bushing (bronz)
1
YM-FUTURELBPDL-
001-BY
Future LB pedal
white
1
YM-HM-02-62 Red brake rubber
MKA062 DMR062
1
YM-HM-02-63
Green brake rubber
MKA063 DMR063
1
YM-HM-02-71
12 thick PLS washer
DMR071
1
