Quick reference replacement parts
Kit name Number Kit contents
Number Name
Quantity
Caster kit, dual
wheel non steer (150
mm), see Brake
system on page 64
YM-KIT-100004 HM-01-26 2946UAP150R36-
32S30 D RAL 9002
4XM6 TENTE 150
mm double lockable
caster (Stryker)
1
HM-05-106 M6*16 imbus bolt 2
HM-09-04 6 mm serrated
washer (ring) DIN
6798
2
HM-11-10 11 mm snap ring
(lipper) KMS starlock
push on BV/6706
fastener
2
HM-11-20
Q11 capped snap
ring DT/6673/44A
2
YM-HM-02-71
12 thick PLS washer
DMR071
2
YM-HM-02-299
50*50 caster profile
cap PLS (lower
chasis PLS) 51
mould
1
Caster kit, dual
wheel steer (150
mm), see Brake
system on page 64
YM-KIT-100003 HM-01-25
2944USP150R36-
32S30 D RAL 9002
4XM6 TENTE 150
mm double
directional caster
(Stryker)
1
HM-05-106 M6*16 imbus bolt 2
HM-09-04 6 mm serrated
washer (ring) DIN
6798
2
HM-11-10 11 mm snap ring
(lipper) KMS starlock
push on BV/6706
fastener
2
HM-11-20
Q11 capped snap
ring DT/6673/44A
2
YM-HM-02-71
12 thick PLS washer
DMR071
2
YM-HM-02-299
50*50 caster profile
cap PLS (lower
chasis PLS) 51
mould
1
