Stryker SV1 - Hi-Lo Actuators

www.stryker.com SM-7100 REV 01 73
Hi-Lo actuators
Item Number Name
Quantity
A HM-17-100
J03648 (31410H
+1115004K CB16 Linak
high/low actuator)
2
B
HM-11-03
10 mm snap ring DIN 471
4
C HM-12-FTR004
12-FTR004 10 x 53
actuator pin
2
D
HM-02-285
10 x 7.5 mm plastic washer
2
E HM-12-112
12-112 Ø10 x 39.5 mm
stepped pin
2
