72 SM-7100 REV 01 www.stryker.com
Bed extender assembly
Item Number Name
Quantity
K HM-11-05
6 mm C shape snap ring
DIN 6799
2
L YM-02-55 Footboard pin socket 2
M HM-08-38 M4 hex nut 2
N YM-HM-02-416
Litter frame plastic end
caps
2
O
YM-HM-02-415 Bed extender block stops 2
P YM-04-FTR023-HZR-BY HPL extension mounting
bracket
2
Q
YM-04-FTR022-HZR-BY HPL extension mounting
bracket
1
R HM-06-02
Ø3.9 x 13 mm Phillips
screw
6
S
HM-08-19 M4 x .7 nylock nut
4
T HM-03-04-03-0650-HZR-
BY
Ø8 mm linen tray bar
1
To Next Page
