Stryker SV1 Service Manual

www.stryker.com SM-7100 REV 01 65
Brake system
Item Number Name
Quantity
F HM-11-10 11 mm snap ring (lipper)
KMS starlock push on
BV/6706 fastener
4
G
YM-HM-02-71
12 mm thick PLS washer
DMR 071
4
H HM-11-20
Q11 capped snap ring
DT/6673/44A
4
I
YM-03-04-10-0760-GL
760 mm hexagonal
galvanized bar
2
J YN-FUTURELBAKT-001-
BY
Brake transfer bar left
2
L HM-05-135 6 X 20 mm steel bolt
4
M HM-12-905
Transfer laser cut part
bushing (bronz)
4
N HM-07-22 M6 iron washer (small)
4
O
HM-08-05
M6 fibered nut
4
P YM-FUTURELBPDL-001-
BY
Future LB pedal white
4
Y YM-HM-02-62 Red brake rubber MKA062
DMR062
4
Z YM-HM-02-63
Green brake rubber
MKA063 DMR063
4
