www.stryker.com KK-7500 REV 02 1-31
Operation
Nurse control pendant
WARNING
• Always lock bed motion controls when the patient is unattended.
• Never store the nurse control panel within the patient’s reach.
CAUTION
• Always place the nurse control pendant onto the footboard.
• Always hang the nurse control pendant onto a foot end siderail or store in the linen tray (option) before removing
the footboard.
• Do not squeeze or pinch the pendant cable in the bed frame.
A B C E
F H
N O
A
G J PD Q S T
R
I
L
K M
Name Function
A
Emergency CPR
Overrides the control panel lockout to achieve the flat
position at low height. Also available if the control
panels are turned off.
B
Litter lockout/Litter lockout LED
Enables or disables locks for litter motion. Illuminates
when you lock the litter section.
C
Litter up
Raises the litter
