www.stryker.com KK-7500 REV 02 1-21
Operation
Applying or releasing steer lock
The steer pedals are located on each caster.
To apply the steer caster, depress the green pedal
(Figure 1-9 on page 1-21). This allows you to maneuver
the product forward and backward in a straight path.
Figure 1-9: Applying the steer pedal
To release the steer caster, depress the red pedal until
the pedal is in the neutral position (Figure 1-10 on page 1-
21). This releases the right side caster on the foot end
and allows you to freely move the product.
Figure 1-10: Releasing the steer pedal
