www.stryker.com KK-7500 REV 02 1-37
Accessories
Adjusting the IV pole
To adjust the IV pole:
1. Turn the telescoping knob counter clockwise to
unlock the IV pole (Figure 1-24 on page 1-37).
2. Grasp the IV pole.
3. Raise the IV pole to the desired height.
4. Turn to the telescoping knob clockwise to lock the IV
pole (Figure 1-24 on page 1-37).
Figure 1-24: Adjusting the IV pole
Installing the lifting pole
The lifting pole assists the patient with changing position in bed.
WARNING
Do not use accessories to support patient limbs or other body parts.
CAUTION
• Always make sure that accessories are locked into position.
• Always remove the lifting pole before transporting the product.
• Do not use the lifting pole as a push or pull device.
• Do not allow accessories to interfere with mechanical or electric mechanisms of the product.
You can install the lifting pole into either of the two accessory sleeves on the head end of the bed.
To install the lifting pole:
