1-36 KK-7500 REV 02 www.stryker.com
Accessories
These accessories may be available for use with your product. Confirm availability for your configuration or region.
CAUTION
Only use authorized accessories for this product. The use of unauthorized accessories may result in product damage or
injury to the operator or patient. Stryker is not responsible for any damage or injury that may result from the misuse of
the product or the use of unauthorized accessories.
Name Number
Safe working load
IV pole
MM017
Each IV hook: 2 kg
Patient lift pole
MM003
75 kg
Upright oxygen bottle holder (120
mm diameter)
MM006
7.5 kg
Foley bag basket
MM029
4 kg
Installing the IV pole
WARNING
Do not use accessories to support patient limbs or other body parts.
CAUTION
• Always make sure that accessories are locked into position.
• Always make sure that the IV pole is at a low height during transport.
• Do not use the IV pole as a push or pull device.
• Do not allow accessories to interfere with mechanical or electric mechanisms of the product.
You can install the IV pole into any of the four accessory sleeves on the corners of the bed. The IV pole has a
telescopic pole that extends to provide a second height position.
To install the IV pole:
1. Insert the IV pole into one of the four accessory sleeves (Figure 1-22 on page 1-36).
2. Rotate and lock the IV pole into the accessory sleeve (Figure 1-23 on page 1-36).
Figure 1-22: Installing the IV pole
Figure 1-23: Locking the IV pole
