Stryker SV2 - Patient Control Panel (Inside Siderail) (Option)

English
EN
1-28 KK-7500 REV 02 www.stryker.com
Operation
Nurse control panel (outside siderail) (option) (Continued)
Name Function
L
Reverse Trendelenburg
Places the product into the Reverse Trendelenburg
position (head up with foot down)
M
Plug indicator Illuminates when the product is plugged in
N
Battery charge indicator
Illuminates amber when you connect the product to a
wall outlet and the batteries are recharging. The
battery has a full charge within 10 to 12 hours. When
the battery is charged, the LED no longer illuminates.
O
Low height indicator
Illuminates green when the product is within 2 cm
from its lowest height position
P
Examination position
Flattens the litter and raises the litter to the highest
height
Q
One-button Vascular position
Overrides the control panel lockout to achieve 12°
Trendelenburg
Patient control panel (inside siderail) (option)
WARNING
Always lock bed motion controls when the patient is unattended.
