pg 23
Flint - tremolo & reverb
External Control
Configuring MultiSwitch Plus
Configure Flint and MultiSwitch Plus for remote access to three
additional presets�
1 Press and hold the TREMOLO ON footswitch while connecting power
to the pedal� Hold until both LEDs stop blinking�
2 Turn the INTENSITY knob all the way counter-clockwise to set the
MIDI channel to Channel 1� The TREMOLO ON LED should be GREEN�
3 Turn the DECAY knob to select any of the following options:
• Send MIDI CC, PC, and Other Data: WHITE
• Send MIDI CC and Other Data: GREEN
• Send MIDI PC and Other Data: PURPLE
• Send Other Data: AMBER
4 Turn the MIX knob all the way clockwise to set the EXP/MIDI jack to
MIDI mode� The REVERB ON LED should be BLUE�
5 Press either footswitch to exit and store the MIDI channel, the MIDI
OUTPUT setting, and the EXP/MIDI jack mode�
6 Connect a TRS cable to Flint’s EXP/MIDI jack�
7 Press and hold the A footswitch on MultiSwitch Plus while connecting
the TRS cable to any one of the three jacks to set it to Preset mode�
