COMPONENTSSTÛV 21
.3 OPTIONAL KITS (NOT INCLUDED)
AIRTIGHT BOX For outside air intake OUTSIDE AIR KIT
Installation p.29
This part is inside
the fireplace
Installation p.27
Follow the instructions supplied with the air damper.
Follow the instructions supplied with the air damper.
ADJUSTABLE STAND To raise the unit AIR DAMPER For outside air intake
5’’ or 6
1/4
’’
1"
1"
+/-
1 ½"
7 ¼"
18 ⁄"
24 ⁄"
21-85 23 ¾"
21-95 27 ⁄"
21-105 29 ⁄"
21-125 37 ½"
WIRE
4’
THREADED ROD
M10 x 3 ½’’
HANDLE
1’’ x ⁄’’
NUT
M10
WASHER
M10
FINISHING WASHER
M5 int.
Ø
4" ou 6"
Ø4"
Ø 4"
It is recommended for 21-95 DF et 21-125 DF models to use
a ø6" outside air kit (not provided by Stûv America)
