Stuv 21 - Installing with Optional Base

34
4
INSTALLATIONSTÛV 21
.6 PREPARING FOR CONVECTION
Step 34 Install the two cement boards on
the floor in the opening where the fireplace
will be installed.
Step 35 Even out the surface in front of
the fireplace with cement board cuttings
so that the fireplace can be later pushed
into the opening.
Step 36 Place the fireplace on the
cuttings at the front of the opening.
Step 37 Using a hammer, remove the pre-
cut pieces of the top rear openings of the
fireplace.
Step 38 Connect a Ø6'' x 20'' long flange
to both upper rear exit of the fireplace
using the maxclip and self-drilling hex
head screws.
403837
363534
10mm
