Stuv 21 - Refractory Bricks

41
4
INSTALLATIONSTÛV 21
.9 REFRACTORY BRICKS
Step 64 Follow the steps on the next
page for the order of installation of the
refractory stones and vermiculites.
Step 65 Identify the model to be installed
and pay attention if there are different
shape stones.
Step 66 Follow the order indicated by the
arrows when installing the top refractory
bricks.
NOTE
For 21-105 SF and 21-125 SF only,
if the refractory bricks on the back
seem unstable follow the steps on
the next page for installation of the
tightening refractory brackets.
!
66
Refractory tightening
clips to be installed
1
10
8
9
8
7
4
3
4
3
2
5
1
2
9
5
10
8
7
11
6
12
1
2
3
4
65
21-105 SF
PW5010100800 x20
(144 x 294 mm )
PW5010100100 x3
(144 x 304 mm)
21-125 SF
PW5010100200 (179 x 367 mm) x14
PW5010213600 (283 x 265mm) x4
PW5010100300 (179 x 354 mm) x3
!!
1
12
17
18
8
19
13
23
16
11
10
15
22
21
20
9
14
6
5
4
3
2
7
9
5
10
8
7
12
6
11
3
4
1
2
21-85 DF
PW5010100900 x8
(169 x 439 mm )
PW5010200005 x2
(330 x 276 mm)
21-95 DF
PW5010100700 (144 x 439 mm) x6
PW5010100900 (169 x 439mm) x4
PW5010200006 (384 x 276 mm) x2
21-125 DF
PW5010100900 x8
(169 x 439 mm )
PW5010200007 x4
(267 x 276 mm)
64
21-85 SF
PW5010101000 x18
(169 x 344mm )
1
12
17
18
8
13
16
11
10
15
9
14
6
5
4
3
2
7
21-95 SF
PW5010101100 x14
(194 x 394 mm)
PW5010213500 x4
(190 x 308 mm)
1
10
15
16
8
17
11
21
14
13
20
19
18
9
12
6
5
4
3
2
7
1
12
17
18
8
13
16
11
10
15
9
14
6
5
4
3
2
7
