Stuv 21 - Simple Face

15
3
DIMENSIONSSTÛV 21
.1 SIMPLE FACE
FRONT VIEW BACK VIEW SIDE VIEW TOP VIEW BOTTOM VIEW
6"
i
H
ø 6"
Anchor
plate
G
F
E
B
C
A
D
4 / "
5 / "
R
T S
P
Q
O
U
ø 6 ¼"
ø V
3 ¾"
J
K
¼"
L
M
FRONT
VIEW
A B C D E F G
21-85 SF 40" 59 /" 51 /" 30 /" 23 /" 26 /" 21 /"
21-95 SF 43 ⁄" 63 /" 56 /" 34 /" 26 /" 30 /" 24 /"
21-105 SF 47 ⁄" 56 /" 48 /" 38 /" 18 /" 34 /" 15 /"
21-125 SF 55 ¾" 59" 51 /" 46 /" 23 /" 42 /" 21 /"
TOP
VIEW
O P Q R S T U V
21-85 SF 25 /" 7 /" 7" 19 /" 7 ¼" 25 /" 10 /" Ø 8"
21-95 SF 27 /" 8 /" 7" 21 /" 7 ¼" 30" 11 /" Ø 10"
21-105 SF 24" 6 /" 6 /" 23 /" 8" 31 /" 11" Ø 8"
21-125 SF 26 /" 7 /" 7 /" 27 /" 8" 39 /" 11 /" Ø 10"
BACK
VIEW
H I
21-85 SF 11 /" 16 /"
21-95 SF 12 /" 18 /"
21-105 SF 13 /" 20 /"
21-125 SF 15 /" 24"
SIDE
VIEW
J K L M
21-85 SF 21" 32 /" 59 /" 14"
21-95 SF 20 /" 36 /" 63 /" 14 /"
21-105 SF 20 /" 29 /" 56 /" 13 /"
21-125 SF 20 /" 32 /" 59" 14 /"
BOTTOM
VIEW
W X Y
21-85 SF 16 /" 13 /" 12 /"
21-95 SF 15 /" 15 /" 15 /"
21-105 SF 17 /" 11 /" 8"
21-125 SF 21 /" 14 /" 11 /"
X
6 ¾"
6 ¼"
W
Y
Glass
