03
© 2022 STYPE; ALL RIGHTS RESERVED.
10
The best distance between Follower witness camera and LED beacon is 2-15m.
Area size
Spyder
4 - 6
20 m
2
NO
6 - 8
50 m
2
NO
8 - 10
150 m
2
NO
10 - 12
250 m
2
NO
8 - 10
20 m
2
YES
10 - 12
50 m
2
YES
12 - 14
150 m
2
YES
14 - 16
250 m
2
YES
FOLLOWER WITNESS CAMERAS AMOUNT CALCULATION
Recommended
number of
witness cameras
For a better understanding of how many Follower witness cameras you need, in the table below you
can find a few more examples containing area size, both using camera tracking and without. (this is a
rough calculation because the exact number depends on the number of spyders, shape of the tracked
surface, possible mounting positions of the cameras and obstacles).
IN - RJ45 ethernet port to connect camera to the POE switch or to the OUT port of another witness camera*
OUT - RJ45 ethernet port to connect more than one camera in a daisy chain on one POE switch line*
-----------------------------------------------------------------------------------------------------------------------------------------------
*more details in chapter 6.2 Daisy chain
Figure 3.4 Follower witness camera ports
OUT IN
