There are multiple options on how to mount the Spyder module on a studio camera. Here are just two
most commonly used options - using the UNIVERSAL MOUNT and using the EXTENSION BAR. Both
mounts are provided with the kit.
5.2 Mounting the Spyder
UNIVERSAL MOUNT
Seamlessly attaches itself to the handle of the camera.
Figure 5.4 Mounting the Spyder module using the Universal mount
FRONT VIEW SIDE VIEW
EXTENSION BAR
Seamlessly attaches itself directly on the camera body.
Figure 5.5 Mounting the Spyder module using the Extension bar
FRONT VIEW SIDE VIEW
