This process is done in the first chapter; Follower Network >> more details in chapter 9.2 Initialization Phases.
PART NUMBER OF PARTS
In-sync (inside of Main Server)
Follower witness camera
Spyder
one
one
connect all of them
connect all of them
MANDATORY / OPTIONAL
mandatory
optional
mandatory
optional
Radio transmitter
First, initialization of the Follower system needs to be done. Some parts are mandatory for the Follower
system while others are optional. If using optional parts, make sure to connect them also. The DHCP server
which is run on the main server will automatically assign a unique IP address to the following parts of the
Follower system:
8.3 Initialization
8.2 Main screen overview (operation mode)
Figure 8.2 Follower main screen
FOLLOWER WITNESS CAMERA SCREENOPERATING ICONS
TRACKING DATA OUTPUT
