11.2 Calibration process
Walk around the area, making sure the four LED beacons on the calibration cross can be seen by at
least two witness cameras at all times. The goal is to have all cameras belonging to the same group.
As the cameras learn their position, you can see the visual representation of their pairing process
(RED rectangle in the image below) at the bottom section of the UI.
Figure 11.5 Calibration cross
body and pipe connection
Figure 11.6 Assembled
calibration cross
Figure 11.7 Calibration process
