04 GET FAMILIAR WITH THE
RADIO TRANSMITTER
Radio transmitter is a device used for syncing radio devices (receivers, Follower pen, mini beacon,
calibration cross, iPad tracker). Operating frequencies are from 864 to 870MHz and odd frequencies
between 903 and 927MHz. It is very important that Follower is the only system using the selected
frequency.
Figure 4.2 Radio transmitter port (PWR)
Figure 4.3 Radio transmitter port (ANT)
PWR
ANT
RADIO TRANSMITTER SPECIFICATION
Weight 0.126 kg
Power POE via CAT6 cable
0.9 x 0.9 cmDimensions
3 W
Power
consumption
Figure 4.1
Radio transmitter
PWR - Power supply RJ45 ethernet port
ANT - Antenna socket
