07 MOUNTING
Follower requires isolated network. Only Follower witness cameras, Spyder and radio transmitter can
be on the same network.
Make sure that the fan of the Follower Main Server is not obstructed.
Before mounting and studio setup, it is recommended to check
connectivity and proper operation of Follower systems parts.
Recommendation is here to avoid needless mounting of cameras just
to find out that one of them is not configured properly.
The Follower Main Server, monitor, and POE switch should be mounted in an easy-to-access place.
It will ease both the installation of the Follower system and possible troubleshooting in the future.
All Follower network devices need to be connected to the POE switch using CAT6 (or higher)
ethernet cables, which provide power and data transfer.
Make sure that the Follower witness cameras
are mounted by using the included magic
arms and clamps to insure a good grip so
that the cameras do not move during and
after calibration of the system. Also, use a
safety cable as a precautionary measure in
case of magic clamp failure to prevent
damage and injury.
7.1 Magic Arm / Clamp and Safety cable
Figure 7.1
Follower witness
camera mounting
