09
WITNESS CAMERA SPECIFICATION
Weight 0.5 kg
Data delay 5 ms
Power
POE via CAT6 cable RJ45
ethernet port IN
Power
7.5 x 9.5 x 9.5 cmDimensions
Positional
resolution
<0.15 mm
Resolution 5.4 megapixel
Connection
up to 8 cameras in sequence
more details in chapter 6.2 Daisy chain
RGB ring
Visual
indicator
810 nm
Observable
wavelenght
Power
consumption
less than 10 W
Figure 3.1 Follower witness camera
Figure 3.2 Follower witness camera
96° FOV horizontally
96°
TOP VIEW
Figure 3.3 Follower witness camera
75° FOV vertically
75°
SIDE VIEW
03 GET FAMILIAR WITH THE
FOLLOWER WITNESS CAMERA
