Below is a hypothetical example of Follower system witness camera studio setup consisting of 10 Follower
witness cameras.
.
Keep in mind that unlike in the previous example in this setup not only object tracking but also camera
tracking is planned and the witness cameras are mounted around the entire area.
7.4 Camera and object tracking
Figure 7.5 Follower witness cameras setup
(object and camera tracking) - TOP VIEW
Figure 7.6 Follower witness cameras setup
(object and camera tracking) - SIDE VIEW
Hint: For best camera tracking, try to have at least one witness camera mounted directly above the
tracked studio camera with a good top view of them. The other eight should be pointing in the
middle of a tracked area, mounted directionally so that each LED beacon is being covered
regardless of movement. Ideally, vertically mounted witness cameras should see all of the LED
beacons in their field of view.
