12
12.2 Regular Studio Setup
© 2022 STYPE; ALL RIGHTS RESERVED.
32
Figure 12.4 Regular setup - FLOOR ALIGN
Figure 12.5 Regular setup - SET Y AXIS
Compared to a QUICK SETUP, REGULAR SETUP takes longer to set up and is more precise.
Place the LED on the floor and click ADD POINT. Do this for at least 4 different points. For greater
accuracy (particulary for large areas), more points can be added.
Raise the LED beacon above the floor plane, then click SET Y AXIS.
