IEC 61850 or
function name
ANSI Function description Breaker
REQ650 (B11)
PROTOCOL Operation selection between SPA and IEC 60870-5-103 for SLM 1
RS485PROT Operation selection for RS485 1
RS485GEN RS485 1
DNPGEN DNP3.0 communication general protocol 1
CHSERRS485 DNP3.0 for EIA-485 communication protocol 1
CH1TCP, CH2TCP,
CH3TCP, CH4TCP
DNP3.0 for TCP/IP communication protocol 1
CHSEROPT DNP3.0 for TCP/IP and EIA-485 communication protocol 1
MSTSER DNP3.0 serial master 1
MST1TCP,
MST2TCP,
MST3TCP,
MST4TCP
DNP3.0 for TCP/IP communication protocol 1
DNPFREC DNP3.0 fault records for TCP/IP and EIA-485 communication protocol 1
IEC 61850-8-1 IEC 61850 1
GOOSEINTLKRCV Horizontal communication via GOOSE for interlocking 59
GOOSEBINRCV GOOSE binary receive 16
GOOSEDPRCV GOOSE function block to receive a double point value 64
GOOSEINTRCV GOOSE function block to receive an integer value 32
GOOSEMVRCV GOOSE function block to receive a measurand value 60
GOOSESPRCV GOOSE function block to receive a single point value 64
GOOSEXLNRCV GOOSE function block to receive a switching device 9
MULTICMDRCV/
MULTICMDSND
Multiple command and transmit 60/10
OPTICAL103 IEC 60870-5-103 Optical serial communication 1
RS485103 IEC 60870-5-103 serial communication for RS485 1
AGSAL Generic security application component 1
LD0LLN0 IEC 61850 LD0 LLN0 1
SYSLLN0 IEC 61850 SYS LLN0 1
LPHD Physical device information 1
PCMACCS IED configuration protocol 1
SECALARM Component for mapping security events on protocols such as DNP3
and IEC103
1
FSTACCS Field service tool access 1
IEC 61850-9-2 Process bus communication, 4 merging units 1-P31
ACTIVLOG Activity logging 1
ALTRK Service tracking 1
PRP IEC 62439-3 Parallel redundancy protocol 1-P23
HSR IEC 62439-3 High-availability seamless redundancy 1-P24
PTP Precision time protocol 1
Table continues on next page
1MRK 505 384-UEN A Section 2
Available functions
Breaker protection REQ650 2.2 IEC 41
Technical manual
