IEC 61850 or
function name
ANSI Function description Breaker
REQ650 (B11)
SSIMG 63 Insulation supervision for gas medium 21
SSIML 71 Insulation supervision for liquid medium 3
SSCBR Circuit breaker condition monitoring 3
EVENT Event function 20
DRPRDRE,
A1RADR-
A4RADR,
B1RBDR-
B22RBDR
Disturbance report 1
SPGAPC Generic communication function for single point indication 64
SP16GAPC Generic communication function for single point indication 16 inputs 16
MVGAPC Generic communication function for measured values 24
BINSTATREP Logical signal status report 3
RANGE_XP Measured value expander block 66
I103MEAS Measurands for IEC 60870-5-103 1
I103MEASUSR Measurands user defined signals for IEC 60870-5-103 3
I103AR Function status auto-recloser for IEC 60870-5-103 1
I103EF Function status earth-fault for IEC 60870-5-103 1
I103FLTPROT Function status fault protection for IEC 60870-5-103 1
I103IED IED status for IEC 60870-5-103 1
I103SUPERV Supervision status for IEC 60870-5-103 1
I103USRDEF Status for user defined signals for IEC 60870-5-103 20
L4UFCNT Event counter with limit supervision 30
TEILGAPC Running hour meter 6
Metering
PCFCNT Pulse-counter logic 16
ETPMMTR Function for energy calculation and demand handling 6
2.3 Communication
GUID-5F144B53-B9A7-4173-80CF-CD4C84579CB5 v15
IEC 61850 or
function name
ANSI Function description Breaker
REQ650 (B11)
Station communication
LONSPA, SPA SPA communication protocol 1
ADE LON communciation protocol 1
HORZCOMM Network variables via LON 1
Table continues on next page
Section 2 1MRK 505 384-UEN A
Available functions
40 Breaker protection REQ650 2.2 IEC
Technical manual
