IEC 61850 or
function name
ANSI Function description Breaker
REQ650 (B11)
AND, GATE, INV,
LLD, OR,
PULSETIMER,
RSMEMORY,
SRMEMORY,
TIMERSET, XOR
Basic configurable logic blocks (see Table 2) 40–420
FXDSIGN Fixed signal function block 1
B16I Boolean to integer conversion, 16 bit 18
BTIGAPC Boolean to integer conversion with logical node representation, 16 bit 16
IB16 Integer to Boolean 16 conversion 18
ITBGAPC Integer to Boolean 16 conversion with Logic Node representation 16
TEIGAPC Elapsed time integrator with limit transgression and overflow
supervision
12
INTCOMP Comparator for integer inputs 30
REALCOMP Comparator for real inputs 30
Table 2: Total number of instances for basic configurable logic blocks
Basic configurable logic block
Total number of instances
AND 280
GATE 40
INV 420
LLD 40
OR 298
PULSETIMER 40
RSMEMORY 40
SRMEMORY 40
TIMERSET 60
XOR 40
IEC 61850 or
function name
ANSI Function description Breaker
REQ650 (B11)
Monitoring
CVMMXN Power system measurement 6
CMMXU Current measurement 10
VMMXU Voltage measurement phase-phase 6
CMSQI Current sequence measurement 6
VMSQI Voltage sequence measurement 6
VNMMXU Voltage measurement phase-earth 6
AISVBAS General service value presentation of analog inputs 1
Table continues on next page
1MRK 505 384-UEN A Section 2
Available functions
Breaker protection REQ650 2.2 IEC 39
Technical manual
